TP-LINK Switch 5x2.5Gbps + 1x10Gbps SFP+ Fémházas Easy Smart (Omada) ES206XPP-M2
73 790
Ft
TP-LINK Switch 5x2.5Gbps + 1x10Gbps SFP+ Fémházas Easy Smart (Omada) ES206XPP-M2
Cikkszám:
723621
Gyártó :
TP-Link
Megbízhatóság:
100%
73 790
Ft
Garancia: 60 hónap
Várható átvétel
| PCX átvevő pont | nov. 02 | |
| Csomagautomata | nov. 03 | |
| MPL Automata | nov. 03 | |
| Posta Pont | nov. 03 | |
| DPD Pont | nov. 03 | |
| MPL Futár | nov. 03 | |
| DPD Futár | nov. 03 | |
| Expressz Futár | nov. 02 |
Tulajdonságok
Bővítő portok száma: 1
Ethernet LAN (RJ-45) portok: 5
Gyártó: TP-LINK
Max. LAN sebesség: 10000
Max. WAN sebesség: 10000
Menedzselhető: Van
Menedzselhetőség: Web
PoE (Power over Ethernet): Nincs
POE portok száma: 4
PoE teljesítmény: 120
Port típusa: 2.5Gb Réz
Portok száma: 10
Rackbe szerelhető: Van
SFP port: 2
Switch típus: Fixed port
Switching kapacitás: 80
WAN: 1
| HARDWARE FEATURES | |
|---|---|
| Interface | • 8× 2.5 Gbps RJ45 Ports • 2× 10 Gbps SFP+ Slots • Auto-Negotiation/Auto MDI/MDIX |
| Fan Quantity | Fanless |
| Installation | • Desktop • Wall Mount |
| Physical Security Lock | |
| Power Supply | DC Power Adapter (Output: 12 VDC / 1.5 A) |
| PoE Ports (RJ45) | • Standard: 802.3af/at/bt PoE++ compliant • PoE Ports: 4 Ports • PoE Budget: 120W available for all PoE++ ports, 90W max per port • Fast PoE & Perpetual PoE • PoE Auto Recovery‡ |
| Dimensions ( W x D x H ) | 8.2 × 5.0 × 1.0 in (209 × 126 × 26 mm) |
| Surge Protection | ±6 kV |
| PERFORMANCE | |
|---|---|
| Packet Buffer Memory | 640 KB |
| Jumbo Frame | 10 KB |
| Switching Capacity | 80 Gbps |
| Packet Forwarding Rate | 59.52 Mpps |
| MAC Address Table | 16K |
| SOFTWARE FEATURES | |
|---|---|
| Quality of Service | • Port-based/802.1p/DSCP QoS • 8 Priority Queues • Priority Schedule Mode - WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control - Port-Based Rating Limit • Storm Control - Multiple Control Modes (kbps/pps) - Broadcast/Multicast/Unknown-Unicast Control |
| L2 Features | • Static Link Aggregation • Loop Prevention / Loopback Detection • Flow Control - 802.3x Flow Control • Mirroring - Port Mirroring - One-to-One - Many-to-One - Ingress/Egress/Both • Port Statistics - Port Mirror Status - Traffic Statistics • 802.1ab LLDP |
| L2 Multicast | • IGMP Snooping - IGMP v1/v2/v3 Snooping - Fast Leave |
| VLAN | • MTU VLAN • Port-Based VLAN • 802.1Q Tag VLAN - Max 32 VLAN Groups - 4K VID |
| Transmission Method | Store-And-Forward |
| Management Features | |
|---|---|
| Omada App | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | • Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller |
| Cloud Access | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Zero-Touch Provisioning | Yes. Requires the use of Omada Cloud-Based Controller |
| Management Features | • Web-based GUI • DHCP Client • Cable Diagnostics • Automatic Device Discovery† • Batch Configuration† • Batch Firmware Upgrading† • Unified Configuration† |
| OTHERS | |
|---|---|
| Certification | FCC, CE, RoHS |
| Package Content | • ES210X-M2 • Power Adapter • Rubber Feet • Installation Guide |
| Environment | • Operating Temperature: -5~40 (23~104) • Storage Temperature: -40~70 (-40~158) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing |
