TP-LINK Switch Ipari 4x1000Mbps + 1xGigabit SFP + 1xGigabit kombó SFP Fémházas, IES206G
64 299
Ft
TP-LINK Switch Ipari 4x1000Mbps + 1xGigabit SFP + 1xGigabit kombó SFP Fémházas, IES206G
Cikkszám:
882839
Gyártó :
TP-Link
Gyártói cikkszám:
IES206G
Megbízhatóság:
100%
64 299
Ft
Garancia: 36 hónap
Várható átvétel
| PCX átvevő pont | okt. 31 | |
| Foxpost | nov. 03 | |
| MPL Automata | nov. 03 | |
| Posta Pont | nov. 03 | |
| DPD Futár | nov. 03 | |
| MPL Futár | nov. 03 | |
| DPD Expressz | okt. 31 | |
| Nagy csomag | nov. 05 |
Tulajdonságok
Gyártó: TP-LINK
Menedzselhetőség: Web
PoE (Power over Ethernet): Nincs
Portok száma: 6
SFP port: 2
Switch típus: Fixed port
| CARATTERISTICHE HARDWARE | |
|---|---|
| Interfaccia | • 4× 10/100/1000 Mbps RJ45 Ports • 1× Gigabit SFP/RJ45 Combo Slot • 1× Gigabit SFP Slot • Auto-Negotiation/Auto MDI/MDIX |
| Numero ventole | Fanless |
| Installation | • DIN-rail mounting • Wall mounting |
| Alimentazione | 9.6-60V 1+1 Redundant DC Power Input |
| Dimensioni ( L x P x A ) | 5.1 × 3.7 × 1.8 in (129 × 95 × 45 mm) |
| Surge Protection | • ±6 kV in common mode for Ethernet ports • ±4 kV in common mode for DC power input ports |
| PRESTAZIONI | |
|---|---|
| Capacita di switching | 12 Gbps |
| Packet Forwarding Rate | 8.93 Mpps |
| Tabella ARP | 8K |
| Buffer (pacchetti) | 4 Mbit |
| Jumbo frame | 15 KB |
| CARATTERISTICHE SOFTWARE | |
|---|---|
| QoS (Quality of Service) | • 802.1p DSCP Priority • 8 Priority Queues • Priority Schedule Mode - WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control - Port-Based Rate Limit • Storm Control - Multiple Control Modes (kbps/pps) - Broadcast/Multicast/Unknown-Unicast Control |
| Funzionalita L2 | • Link Aggregation - Static Link Aggregation - Up to 2 aggregation groups and up to 4 ports per group • Loopback Detection • Flow Control - 802.3x Flow Control • Mirroring - Port Mirroring - One-to-One - Many-to-One - Ingress/Egress/Both • Port Statistics - Port Mirror Status - Traffic Statistics • 802.1ab LLDP • Spanning Tree - STP (802.1d) - RSTP (802.1w) |
| L2 Multicast | • IGMP Snooping - IGMP v1/v2/v3 Snooping - Fast Leave |
| VLAN | • MTU VLAN • Port-Based VLAN • 802.1Q Tag VLAN - Max 32 VLAN Groups - 4K VID |
| Metodo di trasmissione | Store-And-Forward |
| GESTIONE | |
|---|---|
| Omada App | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | • Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller |
| Cloud Access | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Zero-Touch Provisioning | Yes. Requires the use of Omada Cloud-Based Controller |
| Management Features | • Web-based GUI • DHCP Client • Cable Diagnostics • Digital Diagnostic Monitoring (DDM) • Automatic Device Discovery† • Batch Configuration† • Batch Firmware Upgrading† • Unified Configuration† |
| ALTRO | |
|---|---|
| Certificazione | FCC, CE, RoHS |
| Contenuto della confezione | • IES206G • DIN-Rail Mounting Bracket • Wall-Mounting Plates • Installation Guide |
| Ambiente | • Operating Temperature: -40~75 (-40~167) • Storage Temperature: -40~85 (-40~185) • Operating Humidity: 5%~95% non-condensing • Storage Humidity: 5%~95% non-condensing |
