ZYXEL Wireless Access Point Dual Band AX1500 Falra rögíthető + 1 év NCC Pro Pack Bundle, WAX510D-EU0101F
51 599
Ft
ZYXEL Wireless Access Point Dual Band AX1500 Falra rögíthető + 1 év NCC Pro Pack Bundle, WAX510D-EU0101F
Cikkszám:
610556
Gyártó :
Zyxel
Gyártói cikkszám:
WAX510D-EU0101F
Megbízhatóság:
100%
51 599
Ft
Garancia: 24 hónap
Várható átvétel
| PCX átvevő pont | dec. 17 | |
| Foxpost | dec. 19 | |
| MPL Automata | dec. 19 | |
| Posta Pont | dec. 19 | |
| MPL Futár | dec. 19 |
Tulajdonságok
Bridge funkció: Van
Gyártó: ZYXEL
Kültéri kivitel: Nincs
Memória órajel (MHz): 2.4GHz, 5GHz
Rejtett SSID: Igen
Repeater funkció: Van
Sebesség: 1200Mbps
Szabvány: 802.11b, 802.11g, 802.11n, 802.11ac, 802.11ax
Models
WAX510D
Product name
Description
802.11ax (WiFi 6) Dual-Radio Unified Access Point
Wireless
Standard
IEEE802.11 ax/ac/n/g/b/a
MIMO
MU-MIMO
Wireless speed
2.4GHz: 575Mbps
5GHz: 1200Mbps
Frequency band
2.4 GHz (IEEE 802.11 b/g/n)
USA (FCC): 2.412 to 2.462 GHz
Europe (ETSI): 2.412 to 2.472 GHz
5 GHz (IEEE 802.11 a/n/ac)
USA (FCC): 5.15 to 5.35 GHz; 5.725 to 5.850 GHz
European (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz
Bandwidth
20-, 40- and 80-MHz
Conducted typical transmit output power
US (2.4GHz/5GHz): 23/26dBm
EU (2.4GHz/5GHz): 20/25dBm
RF Design
Antenna type
2x2 dual-optimized antenna
Antenna gain
2.4GHz: Peak Gain 5dBi
5GHz: Peak Gain 6dBi
Minimum Receive sensitivity
Min. Rx sensitivity up to -101 dBm
WLAN feature
Band Steering
Yes
WDS
Future Support
Mesh AP (By License)
Future Support
Mesh AP for multiple SSID with VLAN
Future Support
Smart mesh
Future Support
Fast roaming
Pre-authentication, PMK caching and 802.11r
DCS (Auto Channel)
Yes
Load balancing
Yes
Security
Wireless Security
WPA
WPA-PSK
WPA-Enterprise (WPA/WPA2/WPA3)
Access management
L2-isolation
MAC filtering
Rogue AP detection
EAP
IEEE 802.1X
RADIUS authentication
Networking
IPv6
Yes
VLANs
Yes
WMM
Yes
U-APSD
Yes
DiffServ marking
Yes
Management
Operating mode
Nebula Cloud managed
Controller-managed
Standalone
ZON Utility
Discovery of Zyxel switches, APs and gateways
Centralized and batch configurations
IP configuration
IP renew
Device factory reset
Device reboot
Device locating
Web GUI access
Firmware upgrade
Password configuration
One-click quick association with Zyxel AP Configurator (ZAC)
Zyxel AP Configurator
Batch AP configuration
Batch AP firmware upgrade
Batch AP profile backup
Zyxel Wireless Optimizer
WiFi AP planning
WiFi coverage detection
Wireless health management
Web UI/ CLI
Yes
SNMP
Yes
Physical Specifications
Item
Dimensions (WxDxH)(mm/in.)
180 x 180 x 39 / 7.09 x 7.09 x 1.54
Weight (g/lb.)
453g / 1
Packing
Dimensions (WxDxH)(mm/in.)
229 x 216 x 64 / 9.02 x 8.5 x 2.52
Weight (g/lb.)
770g / 1.7
Included accessories
Mount plate
Mounting screws
MTBF (hr)
635,837
Physical Interfaces
Ethernet port
1 x 10/100/1000M LAN
Power
PoE (802.3)at: power draw 17 W
DC input : 12 VDC 1.5A
Environmental Specifications
Operating
Temperature
0°C to 50°C/32°F to 122°F
Humidity
10% to 95% (non-condensing)
Storage
Temperature
-30°C to 70°C/-22°F to 158°F
Humidity
10% to 90% (non-condensing)
Certifications
Radio
FCC Part 15C
FCC Part 15E
ETSI EN 300 328
EN 301 893
LP0002
EMC
FCC Part 15B
EN 301 489-1
EN 301 489-17
EN55022
EN55024
EN61000-3-2/-3
EN60601-1-2
BSMI CNS13438
Safety
Safety EN 60950-1
IEC 60950-1
BSMI CNS14336-1
WAX510D
Product name
Description
802.11ax (WiFi 6) Dual-Radio Unified Access Point
Wireless
Standard
IEEE802.11 ax/ac/n/g/b/a
MIMO
MU-MIMO
Wireless speed
2.4GHz: 575Mbps
5GHz: 1200Mbps
Frequency band
2.4 GHz (IEEE 802.11 b/g/n)
USA (FCC): 2.412 to 2.462 GHz
Europe (ETSI): 2.412 to 2.472 GHz
5 GHz (IEEE 802.11 a/n/ac)
USA (FCC): 5.15 to 5.35 GHz; 5.725 to 5.850 GHz
European (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz
Bandwidth
20-, 40- and 80-MHz
Conducted typical transmit output power
US (2.4GHz/5GHz): 23/26dBm
EU (2.4GHz/5GHz): 20/25dBm
RF Design
Antenna type
2x2 dual-optimized antenna
Antenna gain
2.4GHz: Peak Gain 5dBi
5GHz: Peak Gain 6dBi
Minimum Receive sensitivity
Min. Rx sensitivity up to -101 dBm
WLAN feature
Band Steering
Yes
WDS
Future Support
Mesh AP (By License)
Future Support
Mesh AP for multiple SSID with VLAN
Future Support
Smart mesh
Future Support
Fast roaming
Pre-authentication, PMK caching and 802.11r
DCS (Auto Channel)
Yes
Load balancing
Yes
Security
Wireless Security
WPA
WPA-PSK
WPA-Enterprise (WPA/WPA2/WPA3)
Access management
L2-isolation
MAC filtering
Rogue AP detection
EAP
IEEE 802.1X
RADIUS authentication
Networking
IPv6
Yes
VLANs
Yes
WMM
Yes
U-APSD
Yes
DiffServ marking
Yes
Management
Operating mode
Nebula Cloud managed
Controller-managed
Standalone
ZON Utility
Discovery of Zyxel switches, APs and gateways
Centralized and batch configurations
IP configuration
IP renew
Device factory reset
Device reboot
Device locating
Web GUI access
Firmware upgrade
Password configuration
One-click quick association with Zyxel AP Configurator (ZAC)
Zyxel AP Configurator
Batch AP configuration
Batch AP firmware upgrade
Batch AP profile backup
Zyxel Wireless Optimizer
WiFi AP planning
WiFi coverage detection
Wireless health management
Web UI/ CLI
Yes
SNMP
Yes
Physical Specifications
Item
Dimensions (WxDxH)(mm/in.)
180 x 180 x 39 / 7.09 x 7.09 x 1.54
Weight (g/lb.)
453g / 1
Packing
Dimensions (WxDxH)(mm/in.)
229 x 216 x 64 / 9.02 x 8.5 x 2.52
Weight (g/lb.)
770g / 1.7
Included accessories
Mount plate
Mounting screws
MTBF (hr)
635,837
Physical Interfaces
Ethernet port
1 x 10/100/1000M LAN
Power
PoE (802.3)at: power draw 17 W
DC input : 12 VDC 1.5A
Environmental Specifications
Operating
Temperature
0°C to 50°C/32°F to 122°F
Humidity
10% to 95% (non-condensing)
Storage
Temperature
-30°C to 70°C/-22°F to 158°F
Humidity
10% to 90% (non-condensing)
Certifications
Radio
FCC Part 15C
FCC Part 15E
ETSI EN 300 328
EN 301 893
LP0002
EMC
FCC Part 15B
EN 301 489-1
EN 301 489-17
EN55022
EN55024
EN61000-3-2/-3
EN60601-1-2
BSMI CNS13438
Safety
Safety EN 60950-1
IEC 60950-1
BSMI CNS14336-1
