ZYXEL Switch 24x 2.5G AC:700W PoE , DC:1440W PoE, 4 x SFP+ Uplink, incl 1 yr NebulaFlex Pro, XMG2230-28HP-ZZ0101F
361 890
Ft
ZYXEL Switch 24x 2.5G AC:700W PoE , DC:1440W PoE, 4 x SFP+ Uplink, incl 1 yr NebulaFlex Pro, XMG2230-28HP-ZZ0101F
Cikkszám:
821321
Gyártó :
Zyxel
Gyártói cikkszám:
XMG2230-28HP-ZZ0101F
Megbízhatóság:
100%
361 890
Ft
Garancia: 36 hónap
Várható átvétel
| PCX átvevő pont | okt. 29 | |
| Csomagautomata | okt. 30 | |
| MPL Automata | okt. 30 | |
| Posta Pont | okt. 30 | |
| DPD Pont | okt. 30 | |
| MPL Futár | okt. 30 | |
| DPD Futár | okt. 30 | |
| Expressz Futár | okt. 29 |
Tulajdonságok
10G támogatás: Igen
Alapvető kapcsolási RJ-45 Ethernet portok száma: 24
Alapvető kapcsolási RJ-45 Ethernet portok típusa: 2.5G Ethernet (100/1000/2500)
Ethernet-áramellátás (PoE) támogatása: Igen
Hálózati szabvány: IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1ad,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3af,IEEE 802.3an,IEEE 802.3at,IEEE 802.3az,IEEE 802.3bt,IEEE 802.3bz,IEEE 802.3x,IEEE 802.3z
Kapcsolási kapacitás: 200 Gbit/s
Kapcsoló típusa: Vezérelt
Keretállvány: Igen
LED-kijelzők: Igen
MAC-címtábla: 32000 bejegyzés(ek)
magasság: 44 mm
Mélység: 330 mm
Relatív üzemi páratartalom-tartomány: 5 - 95 %
Szélesség (mm): 441
Tanúsítványok: FCC Part 15 (Class A)CE EMC (Class A)BSMI EMC
Tárolási hőmérséklettartomány (T-T): -40 - 70 °C
Termék színe: Fekete
Tömeg: 4530 g
Üzemi hőmérséklettartomány (T-T): -20 - 50 °C
Description
Product name
24-port 2.5G PoE L3 Access Switch with 4 10G Uplink
Switch class
Layer 3 Access
Port Density
Total port count
28
10M/100M/1G (RJ-45)
-
100M/1G/2.5G Ethernet (RJ-45)
24
10 Gigabit SFP+
4
PoE
PoE ports
24
Total PoE budget (watts)
Internal AC input: 700
External DC input: 1,440
IEEE 802.3at (PoE+)
-
IEEE 802.3bt PoE++ (60W)
Yes
Port 1 ~ Port 24 (100M/1G/2.5G)
Performance
Switching capacity (Gbps)
200
Forwarding rate (Mpps)
148.8
Packet buffer (byte)
2MB
MAC address table
32K
Jumbo frame (byte)
12KB
L3 forwarding table (IPv4/IPv6)
Max. 2K IPv4 entries;
Max. 2K IPv6 entries
Routing table
64
VLAN routing
Yes
IP interface (IPv4/IPv6)
32/32
Flash/RAM
64MB/1GB
Power
Input
100-240V AC, 50/60Hz
50-57V DC
Min. power consumption (watts)
Without any port connection
AC: 32.6/DC: 25.5
Max. power consumption (watts)
All ports full load without PoE
AC: 64.7/DC: 51.5
Max. power consumption (watts)
All ports full load with PoE
AC: 842.3/DC: 1519.1
Physical Specifications
Dimensions
(WxDxH)(mm/in.)
441 x 330 x 44/17.36 x 12.99 x 1.73
Weight
(kg/lb.)
4.53/9.99
Included accessories
Power cord
Rack mounting kit
ESD/Surge Protections
Ethernet port surge protection
2KV
Power supply surge protection
Line-GND: 2KV
LIne-Line: 1KV
ESD protection (air/contact)
8KV/6KV
Environmental Specifications
Operating
Temperature: -20°C to 50°C/-4°F to 122°F
Humidity: 5% to 95% (non-condensing)
Storage
Temperature: -40°C to 70°C/-40°F to 158°F
Humidity: 5% to 95% (non-condensing)
MTBF (hr @ 25°C)
AC: 554,612.62/DC: 483,006.55
Heat dissipation (BTU/hr)
2,856
Acoustic noise @ 25°C (min/max, dBA)
28.92/48.85
