Walisec kültéri toldó - RJ45-KC6SW (Cat6, árnyékolt, IP68)
1 999
Ft
Walisec kültéri toldó - RJ45-KC6SW (Cat6, árnyékolt, IP68)
Cikkszám:
257184
Gyártó :
WaliSec
Gyártói cikkszám:
RJ45-KC6SW
Megbízhatóság:
100%
1 999
Ft
Garancia: 60 hónap
Várható átvétel
| PCX átvevő pont | dec. 17 | |
| Posta Pont | dec. 19 | |
| MPL Futár | dec. 19 |
Tulajdonságok
Típus: Kiegészítõ
|
Connector Type |
|
|
Category |
Cat 6 |
|
Connector |
2x RJ45(8P8C) Female Ports |
|
Shielding |
Shielded |
|
|
|
|
Material |
|
|
Housing Material |
Nylon PA66 |
|
Contact Material |
Phosphor Bronze, Stamped Pin, Thickness = 0.35mm |
|
Contact Surface Material |
Gold Plating, thickness = 3U (3μin or 0.0762 µm) |
|
|
|
|
Electrical Properties |
|
|
Transmission Frequency |
250 MHz |
|
Voltage/Current Rating |
125 VAC / 1.5 A |
|
Insulation Resistance |
≥ 1000 MΩ |
|
Contact Resistance |
≤ 100 mΩ at 500 VDC |
|
Dielectric Strength |
750 VAC RMS, 60Hz, 1 minute |
|
|
|
|
Mechanical Properties |
|
|
Durability |
≥ 750 mating cycles |
|
Wire Diameter |
4 mm ≤ ODO ≤ 8 mm |
|
|
|
|
Environment |
|
|
Operating Temperature |
-40°C to 70°C |
|
Operating Humidity |
RH 10% to 90% (non-condensing) |
|
Storage Temperature |
-40°C to 80°C |
|
Storage Humidity |
RH 5% to 96% (non-condensing) |
|
|
|
|
General |
|
|
Dimension |
O28x121.5 mm (Diameter x Length) |
|
Net Weight |
47 g |
|
|
|
|
Diagram |
unit: mm |
