UBiQUiTi POE Adapter 2,5Gbps, 30W, 48VDC 0.65A - UACC-POE+-2.5G
8 691
Ft
UBiQUiTi POE Adapter 2,5Gbps, 30W, 48VDC 0.65A - UACC-POE+-2.5G
Cikkszám:
212289
Gyártó :
Ubiquiti
Gyártói cikkszám:
UACC-POE+-2.5G
Megbízhatóság:
100%
8 691
Ft
Garancia: 24 hónap
Várható átvétel
| PCX átvevő pont | okt. 27 | |
| DPD Pont | okt. 28 | |
| MPL Automata | okt. 28 | |
| Posta Pont | okt. 28 | |
| MPL Futár | okt. 28 | |
| DPD Futár | okt. 28 | |
| Expressz Futár | okt. 27 |
Tulajdonságok
Csatlakozó: RJ45
Gyártó: UBIQUITI
LAN Portok: 2
Szín: Fehér
Típus: Adapter
Kompatibilitás
U7-Pro
U7-Outdoor
U7-Pro-Max
U7-Pro-Wall
U7-Pro-Outdoor
U7-IW
U7-Lite
U6-Enterprise-IW
U6-Enterprise
| Dimensions | 93 x 62 x 35 mm (3.7 x 2.4 x 1.4") |
| Weight | 156 g (5.5 oz) |
| Output voltage | 48V DC @ 0.65A |
| LAN activity indicator | No |
| Gigabit LAN port | Yes, up to 2.5 GbE |
| Remote reset capability | No |
| Reset button | No |
| Rated voltage | 100—240V AC @ 50/60Hz |
| Input current | 0.75A max. |
| Inrush current | <150A peak @ 230V AC |
| Efficiency | >87% |
| Output ripple | 1% max. |
| Switching frequency | 65 kHz max. |
| Line regulation | ≤ 1% |
| Load regulation | ≤ 3% |
| 2-pair powering | Pins 4, 5 (+) and 7, 8 (-) |
| 4-pair powering | No |
| Data In / PoE | RJ45 shielded socket |
| Surge protection | Difference and common mode |
| Clamping protection | 11V data, 60V power |
| Max. surge discharge | 1500A (8/20 μs) power |
| Peak pulse current | 36A (10/1000 μs) data |
| Shunt capacitance | <5 pF data |
| Response time | <1 ns |
| Ambient operating temperature | 0 to 40° C (32 to 104° F) |
| Storage temperature | -30 to 70°C (-22 to 158° F) |
| Ambient operating humidity | 10 to 95% noncondensing |
| Certifications | CE, FCC, IC, UL, UKCA, KC, CCC, RoHS |
