TP-LINK Video recorder 8 csatornás POE+, VIGI NVR2008H-8MP

Name: TP-LINK Video recorder 8 csatornás POE+, VIGI NVR2008H-8MP
Brand: TP-Link
SKU: 170458
Price: 219999.56 HUF
Availability: InStock

Cikkszám: 170458

Gyártó : TP-Link

Gyártói cikkszám: VIGI NVR2008H-8MP

Megbízhatóság: 100%

220 000 Ft

Garancia: 36 hónap

Várható átvétel

PCX átvevő pont	okt. 17
Posta Pont	okt. 20
DPD Futár	okt. 20
MPL Futár	okt. 20
DPD Expressz	okt. 17
Nagy csomag	okt. 22

Tulajdonságok

Csatornák száma: 8

HDD csatolófelület: SATA

HDD száma: 2

IP kamera rögzítés: 80

LAN csatlakozó szám: 9

LAN csatlakozók száma: 9

Max rögzíthető csatornák száma: 8

Max. HDD kapacitás portonként: 16000

Max. IP kamera felbontás: 8MP

Max. LAN sebesség: 100

Max. merevlemezek száma: 2

Onvif támogatás: Van

Tömörítés: H265+/H265/H264+/H264

USB 2.0: 2

Video kimenetek típusa: 1x VGA + 1x HDMI

Video and Audio
IP Video Input	8-Channel
Incoming Bandwidth	80 Mbps
Outgoing Bandwidth	60 Mbps
HDMI Output Resolution	1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
VGA Output Resolution	1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
Video Output Mode	HDMI/VGA Simultaneous Output
Multi-View Display	1/4/6/8

DECODING
Audio Compression	G.711A/G.711U/G.726
Video Compression	H.265+/H.265/ H.264+/H.264
Record Resolution	8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous Playback	8-Channel^†
Capability	• 25fps: 2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP • 30fps: 4-ch @ 3MP, 2-ch @ 5MP

Record Management
Record Mode	• Manual Recording • Scheduling Recording • Motion Detection Recording
Playback Mode	• Instant Playback • Regular Playback • Tag Playback • Event Playback
Backup Mode	• Regular Backup • Video Clip Backup
Playback Function	• Play • Pause • Stop • Fast Forward • Fast Backward • Play By Frame • Full Screen • Video Clip • Export Clip • Digital Zoom • Lock Recording • Audio On/Off

NETWORK
Protocol	UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP
Mobile Phone Access	Android, iOS
Web Browser	Chrome (57+), Firefox (52+), Edge (91+)
Interoperability	ONVIF, CGI

External Interface
Network Interface	1, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
USB Interface	1 Front USB 2.0 Port, 1 Rear USB 2.0 Port
Audio Interface	1-ch RCA Input; 1-ch RCA Output
Alarm In/Out	N/A
Serial Interface	N/A
Power	1× DC Jack
Reset Button	1
Speaker	N/A
eSATA	1
HDMI	1
VGA	1

HARD DISK
SATA	2 SATA Interfaces
Capacity	Up to 16 TB Capacity for Each HDD*

PoE
Standard	802.3at/af Compliant
Interface	1-8, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
PoE Budget	93 W Available for All PoE+ Ports, 30 W Max per Port

Alarm
General Alarm	• Motion Detection • Video Tampering • Scene Change Detection • Line-Crossing Detection • Intrusion Detection • Region Entering Detection • Region Exiting Detection • Loitering Detection • Object Abandoned/Removal Detection • Vehicle Detection • Human Detection • Abnormal Sound Detection • Smart Frame
Anomaly Alarm	• Video Loss • Offline and IP Conflict • Disk Exception • Login Exception • Fan Exception
Alarm Linkage	• Recording • White Light Alarm • Buzzer • Log • Audible Alarm

GENERAL
Storage Temperature	-40–70 °C
Storage Humidity	10%~90% RH Non-Condensing
Package Contents	• VIGI Network Video Recorder • Power Adapter • Power Cables • HDD Power Cables • HDD Data Cables • Mounting Accessories • Mouse • Quick Installation Guide
Working Temperature	• NVR: -10–55 °C • Power Adapter: 0–40 °C
Working Humidity	10%~90% RH Non-Condensing
Dimensions( W X D X H )	330 × 285 × 45 mm
Net Weight	2.1 Kg^§
Gross Weight	4.1 Kg^§
Power Supply	53.5V DC/2.43A
Power Consumption	• 4.9 W (Without Disk) • 35 W (With Disk)
Certifications	CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI
