TP-LINK Switch 9x1000Mbps (8xPOE+) +1xGigabit SFP kombó Fémházas Easy Smart (Omada), ES210GMP
51 190
Ft
TP-LINK Switch 9x1000Mbps (8xPOE+) +1xGigabit SFP kombó Fémházas Easy Smart (Omada), ES210GMP
Cikkszám:
327834
Gyártó :
TP-Link
Gyártói cikkszám:
ES210GMP
Megbízhatóság:
100%
51 190
Ft
Garancia: 60 hónap
Várható átvétel
| PCX átvevő pont | márc. 20 | |
| Foxpost | márc. 23 | |
| MPL Automata | márc. 23 | |
| Posta Pont | márc. 23 | |
| DPD Futár | márc. 23 | |
| MPL Futár | márc. 23 | |
| MPL Expressz | márc. 20 |
Tulajdonságok
Áteresztő képesség: 14,8800000
Bővítő portok száma: 1
Ethernet LAN (RJ-45) portok: 10
Gyártó: TP-LINK
Max. LAN sebesség: 1000
Max. WAN sebesség: 1000
Menedzselhető: Van
Menedzselhetőség: Web
PoE (Power over Ethernet): Van
POE portok száma: 8
PoE teljesítmény: 123
Port típusa: 1Gb Réz
Portok száma: 10
Rack-be szerelhető: Van
Rackbe szerelhető: Nincs
SFP port: 1
Switch típus: Modular
Switching kapacitás: 20
WAN: 1
| HARDWARE FEATURES | |
|---|---|
| Interface | • 8× 10/100/1000 Mbps PoE+ RJ45 Ports (support 802.3at PoE+ and 802.3af PoE) • 1× 10/100/1000 Mbps RJ45 Port • 1× Gigabit SFP/RJ45 Combo Port • Auto-Negotiation/Auto MDI/MDIX |
| Fan Quantity | Fanless |
| Installation | • Desktop • Wall Mount |
| Physical Security Lock | |
| Power Supply | DC Power Adapter (Output: 53.5 VDC/ 2.43 A) |
| PoE Ports (RJ45) | • Standard: 802.3af PoE and 802.3at PoE+ compliant • PoE Ports: 8 ports • PoE Budget: 123W available for all PoE+ ports, 30W max per port • PoE Auto Recovery‡ • Up to 250m PoE transmission distance** |
| Dimensions ( W x D x H ) | 8.2×4.9×1.0 in (209×126×26 mm) |
| Surge Protection | ±6kV |
| PERFORMANCE | |
|---|---|
| Switching Capacity | 20 Gbps |
| Packet Forwarding Rate | 14.88 Mpps |
| MAC Address Table | 8K |
| Packet Buffer Memory | 4 Mbit |
| Jumbo Frame | 15 KB |
| SOFTWARE FEATURES | |
|---|---|
| Quality of Service | • Port-based/802.1p/DSCP QoS • 8 Priority Queues • Priority Schedule Mode - WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control - Port-Based Rating Limit • Storm Control - Multiple Control Modes (kbps/pps) - Broadcast/Multicast/Unknown-Unicast Control |
| L2 Features | • Static Link Aggregation • Loop Prevention / Loopback Detection • Flow Control - 802.3x Flow Control • Mirroring - Port Mirroring - One-to-One - Many-to-One - Ingress/Egress/Both • Port Statistics - Port Mirror Status - Traffic Statistics • 802.1ab LLDP |
| L2 Multicast | • IGMP Snooping - IGMP v1/v2/v3 Snooping - Fast Leave |
| VLAN | • MTU VLAN • Port-Based VLAN • 802.1Q Tag VLAN - Max 32 VLAN Groups - 4K VID |
| Transmission Method | Store-And-Forward |
| Management Features | |
|---|---|
| Omada App | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | • Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller |
| Cloud Access | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Zero-Touch Provisioning | Yes. Requires the use of Omada Cloud-Based Controller |
| Management Features | • Web-based GUI • DHCP Client • Cable Diagnostics • Automatic Device Discovery† • Batch Configuration† • Batch Firmware Upgrading† • Unified Configuration† |
| OTHERS | |
|---|---|
| Certification | FCC, CE, RoHS |
| Package Content | • ES210GMP • Power Adapter • Installation Guide • Rubber Feet |
| Environment | • Operating Temperature: 0~40 (32~104) • Storage Temperature: -40~70 (-40~158) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing |
