| PERFORMANCE |
| Display Size |
23.8“ |
| View Area |
526.8x296.4 mm |
| Panel |
In-Plane Switching |
| Backlight |
WLED |
| Aspect Ratio |
16:9 |
| Resolution |
2560x1440 |
| Pixel Pitch |
0.2058x0.2058 mm |
| Dot / Pixel Per Inch |
123 dpi |
| View Angle (H / V) |
178° / 178° |
| Response Time |
4ms (Extreme mode) / 6ms (Normal mode) |
| Color Support |
16.7 Million |
| Refresh Rate |
48Hz - 120Hz |
| Brightness |
300 cd/m2 |
| Contrast Ratio |
1500:1 |
| Color Gamut |
99% sRGB, 99% BT.709 |
| Screen Surface Treatment |
Anti-glare |
| Curvature |
Flat Panel |
| Camera |
Modular Camera Support |
| Microphone |
None |
| Speakers |
Modular Speaker Support |
| Power Consumption (Typical / Maximum) |
16.5W / 210W |
| Power Adapter |
Integrated |
| Touchscreen |
None |
| Smart System |
None |
| DESIGN |
| Stand |
Tilt, Swivel, Pivot, Height Adjust Stand |
| Case Color |
Eclipse Black |
| Side Bezel Width |
2 mm |
| Mounting |
Supports VESA mount 100 x 100 mm |
| ThinkCentre M Series Support |
Tiny Support |
| Pen |
None |
| Dimensions (WxDxH) |
- Lowest Position | 539.8 x 190.0 x 350.8 mm (21.25 x 7.48 x 13.81 inches)
- Highest Position | 539.8 x 190.0 x 505.8 mm (21.25 x 7.48 x 19.91 inches)
- Head Only | 539.8 x 45.3 x 315.8 mm (21.25 x 1.78 x 12.43 inches)
|
| Packaging Dimensions (WxDxH) |
730 x 123 x 420 mm (28.74 x 4.84 x 16.54 inches) |
| Weight |
- Monitor With Stand | 5.6 kg (12.4 lbs)
- Monitor Head Only | 3.6 kg (8.0 lbs)
|
| Packaging Weight |
8.4 kg (18.4 lbs) |
| CONNECTIVITY |
| USB Port |
x USB-C® (USB 10Gbps,DP 1.4 Alt Mode HBR3, PD3.1 140W, USB upstream), 1x USB-B (USB 5Gbps, USB upstream), 4x USB-A (USB 5Gbps, 1x BC1.2, USB downstream), 1x USB-C (USB 5Gbps, 15WPD, USB downstream) |
| Video Connector |
1x HDMI® 2.1 TMDS, 1x DP 1.4 (HBR3), 1x DP 1.4 Out, 1x USB-C® (10Gbps, DP 1.4 Alt Mode HBR3) |
| Network Connectivity |
1x RJ45, Ethernet (10M/100M/1000M/2500M) |
| SERVICE |
| Base Warranty |
3-year |
| CERTIFICATIONS |
| Environmental Certification |
ENERGY STAR® Certified,TCO 10.0, TCO Edge 2.1, EU Energy Efficiency Level (Level-D), EPEAT™ Gold |
| Ergonomic Certification |
TÜV Rheinland® Eye Comfort 5 Stars, Eyesafe® Display 2.0, TÜV Low Blue Light (Hardware solution) |
| Sync Technology |
None |
| Special Features |
- HDR10 Compliance
- Factory Calibration: Avg. Delta E<2 at sRGB
- Lenovo® ThinkColour (Lenovo Accessories and Display Manager) Support Lenovo ThinkColour supports Windows® 10 & 11, Mac OS (functions vary across systems). Lenovo Accessories and Display Manager is formerly Lenovo Display Control Center.
- KVM Switch (with eKVM)
- LDFM (Lenovo® Display Fleet Manager)
- Mirrored Power Button
- Multi-sync
- Natural Low Blue Light
- Smart Power
|
| SOFTWARE |
| Operating System |
Support Windows® 10, Windows 11 |
| ACCESSORIES |
| Video Cables |
DP cable, USB-C® to USB-C Gen 2 cable, USB-B to USB-A Gen 1 cable |
| MODEL INFORMATION |
| Model |
64B1GAT1EU |
| Machine Type |
64B1 |
| Region |
EMEA |
| EAN / UPC / JAN |
0198156544872 / 198156544872 / None |
| Announce Date |
2025-06-12 |
