PERFORMANCE |
Display Size |
23.8“ |
View Area |
526.8x296.4 mm |
Panel |
In-Plane Switching |
Backlight |
WLED |
Aspect Ratio |
16:9 |
Resolution |
2560x1440 |
Pixel Pitch |
0.2058x0.2058 mm |
Dot / Pixel Per Inch |
123 dpi |
View Angle (H / V) |
178° / 178° |
Response Time |
4ms (Extreme mode) / 6ms (Normal mode) |
Color Support |
16.7 Million |
Refresh Rate |
48Hz - 120Hz |
Brightness |
300 cd/m2 |
Contrast Ratio |
1500:1 |
Color Gamut |
99% sRGB, 99% BT.709 |
Screen Surface Treatment |
Anti-glare |
Curvature |
Flat Panel |
Camera |
Modular Camera Support |
Microphone |
None |
Speakers |
Modular Speaker Support |
Power Consumption (Typical / Maximum) |
12W / 65W |
Power Adapter |
Integrated |
Touchscreen |
None |
Smart System |
None |
DESIGN |
Stand |
Tilt, Swivel, Pivot, Height Adjust Stand |
Case Color |
Raven Black |
Side Bezel Width |
2 mm |
Mounting |
Supports VESA mount 100 x 100 mm |
ThinkCentre M Series Support |
Tiny Support |
Pen |
None |
Dimensions (WxDxH) |
- Lowest Position | 539.8 x 190.0 x 350.8 mm (21.25 x 7.48 x 13.81 inches)
- Highest Position | 539.8 x 190.0 x 505.8 mm (21.25 x 7.48 x 19.91 inches)
- Head Only | 539.8 x 45.3 x 315.8 mm (21.25 x 1.78 x 12.43 inches)
|
Packaging Dimensions (WxDxH) |
730 x 123 x 420 mm (28.74 x 4.84 x 16.54 inches) |
Weight |
- Monitor With Stand | 5.1 kg (11.2 lbs)
- Monitor Head Only | 3.0 kg (6.6 lbs)
|
Packaging Weight |
7.6 kg (16.7 lbs) |
CONNECTIVITY |
USB Port |
1x USB-B (USB 5Gbps, USB upstream), 3x USB-A (USB 5Gbps, 1x BC1.2, USB downstream), 1x USB-C® (USB 5Gbps, 15W PD, USB downstream) |
Video Connector |
1x HDMI® 2.1 TMDS, 1x DP 1.4 (HBR2), 1x DP 1.4 Out |
Network Connectivity |
None |
SERVICE |
Base Warranty |
3-year |
CERTIFICATIONS |
Environmental Certification |
ENERGY STAR® Certified,TCO 10, TCO Edge 2.1, EU Energy Efficiency Level (Level-C), EPEAT™ Gold |
Ergonomic Certification |
TÜV Rheinland® Eye Comfort 5 Stars, Eyesafe® Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Flicker Free |
Sync Technology |
None |
Special Features |
- HDR10 Compliance
- Factory Calibration: Avg. Delta E<2 at sRGB
- Lenovo® ThinkColour (Lenovo Accessories and Display Manager) Support Lenovo ThinkColour supports Windows® 10 & 11, Mac OS (functions vary across systems). Lenovo Accessories and Display Manager is formerly Lenovo Display Control Center.
- LDFM (Lenovo® Display Fleet Manager)
- Multi-sync
- Natural Low Blue Light
|
SOFTWARE |
Operating System |
Support Windows® 10, Windows 11 |
ACCESSORIES |
Video Cables |
DP cable, HDMI® cable |
MODEL INFORMATION |
Model |
64B2GAT1EU |
Machine Type |
64B2 |
Region |
EMEA |
EAN / UPC / JAN |
0198156604378 / 198156604378 / None |
Announce Date |
2025-06-09 |
