V600R022C10
Integrated fixed device
Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.)
Dimensions with packaging (H x W x D) [mm(in.)]
1
Installation type
2.71 (5.97)
Weight with packaging [kg(lb)]
44.9
Typical heat dissipation [BTU/hour]
52.05
Maximum heat dissipation [BTU/hour]
27.55
100% power consumption [W]
40.61
MTTR [hour]
>0.99999
Noise at normal temperature (acoustic power) [dB(A)]
54.3
Noise at normal temperature (acoustic pressure) [dB(A)]
0
Number of power slots
1
Maximum number of physical ports on the entire device
0
Maximum number of 40GE ports
0
Maximum number of 10GE ports
0
Maximum number of 2.5GE ports
52
Maximum number of FE ports
Not supported
Redundant power supply
-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.)
Restriction on the operating temperature variation rate [°C(°F)]
–40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH]
0–5000 m (0–16404 ft.)
Storage altitude [m(ft.)]
AC built-in
Rated input voltage [V]
AC input: 90–290 V AC; 45–65 Hz
Maximum input current [A]
1.1 GHz, 2 cores
Memory
1 GB in total. To view the available flash memory size, run the display version command.
Console port
Not supported
USB
Not supported
Dying gasp
Not supported
RPS input
Not supported
Service port surge protection [kV]
Differential mode: ±6 kV; common mode: ±6 kV
Ingress protection level (dustproof/waterproof)
Built-in
Heat dissipation mode
Air intake from left and air exhaust from right
PoE
-
PoE+ power interfaces
-
Full load PoE power consumption 15.4W (802.3af)
-
Full load PoE++ power consumption 60W (802.3bt)
-
Certification
