D-LINK USB-C HUB 3xUSB + 1xUSB-C +1xLAN, DUB-2334

Hardware




Chipset


• RTL8153




Interfaces


• One USB Type-C connector

• Three USB 3.0 Type-A ports

• One USB Type-C/PD 3.0 port

• One RJ-45 Ethernet port (10/100/1000 Mbps)




LEDs


• Power (per device)

   - Solid green - power is on

• Link (per Ethernet port)

   - Solid green - Ethernet connection

• Speed (per Ethernet port)

   - Flashing orange - data transmission




General




Standards


• USB 3.0

• USB 2.0

• USB 1.1

• IEEE 802.3 10Base-T

• IEEE 802.3u 100Base-TX

• IEEE 802.3ab 1000Base-T

• Pause mode

• Wake-on-LAN




Data rate


• Up to 5 Gbps (USB 3.0)

• Up to 1000 Mbps (Ethernet)




System requirements


• Available USB Type-C port

• Windows 7/8/8.1/10 and above, macOS (OS X 10.8 and above)




Physical Parameters




Dimensions (L x W x H)


• 118 x 35 x 13.5 mm




Weight


• 0.07 kg




Environmental Conditions




Power input


• From computer (USB bus powered)




Supplied charging voltage/current


• 20 V / 3 A (PD 3.0)




Temperature


• Operating: 0 to 45°C

• Storage: -10 to 70°C




Humidity


• Operating: up to 85% non-condensing

• Storage: up to 85% non-condensing




Package Contents




• DUB-2334 docking station

• Quick Installation Guide

• Warranty documents
