CHIEFTEC Tápegység ELEMENT 400W 80+ Bronze OEM ELP-400S-BULK

Model
ELEMENT 400W


Article no.
ELP-400S


EAN code
4710713230941


Weight (without/with package)
1.4kg / 1.67kg


AC Input
200-240V / 3.0A


Frequency
47 - 63Hz


+5V
16A


+3,3V
17A


+5V & +3,3V combined
100W


+12V1
30A


+12V2
-


+12V1, +12V2 combined
360W


P.F.
>0,9


-12V
0,3A / 3,6W


+5VSB
2,5A / 12,5W


Maximum Power
400W






Connectors


20+4 PIN ATX
1


8 PIN EPS(4 PIN PCIe (6+2)
1


SATA
3


MOLEX/FLOPPY
2/1






Cable length (mm)


20+4 PIN ATX
500


8 PIN EPS(4 PIN PCIe (6


SATA
500/150/150


MOLEX/FLOPPY
500/150/150






Features


ATX12V Version
ATX 12V 2.3


Efficiency
>85%


Dimension (DxWxH)
140 mm x 150 mm x 86 mm


PFC
Active PFC (0,9)


Fan
120mm silent fan


Security
AFC (Automatic Fan speed Control)
OPP (Over Power Protection)
OVP (Over Voltage Protection)
SCP (Short Circuit Protection)
SIP (Surge & Inrush Protection)
UVP (Under Voltage Protection)


Warranty
24 Months
