General Specifications
Memory Capacity
Standard
ADS-1300: 256 MB
ADS-1350W/ADS-1800W: 512 MB
Power Source
DC
5V, 3A *1
AC Adapter *2
INPUT: AC 100 to 240 V 50/60 Hz
OUTPUT: DC 5V, 3A
Touchscreen LCD (Liquid Crystal Display) *3
(ADS-1800W)
Touchscreen 71.1 mm TFT Colour LCD
Power Consumption *4 *5
Scanning *6
ADS-1300
AC: Approximately 11 W
DC: Approximately 9 W
ADS-1350W
AC: Approximately 11 W
DC: Approximately 9 W
ADS-1800W
AC: Approximately 12 W
DC: Approximately 10 W
Ready
ADS-1300
AC: Approximately 5 W
DC: Approximately 4 W
ADS-1350W
AC: Approximately 5.5 W
DC: Approximately 4.4 W
ADS-1800W
AC: Approximately 6.4 W
DC: Approximately 5.2 W
Sleep
ADS-1300
AC: Approximately 1.3 W
DC: Approximately 1 W
ADS-1350W
AC: Approximately 1.4 W
DC: Approximately 1 W
ADS-1800W
AC: Approximately 1.5 W
DC: Approximately 1.1 W
Power Down
ADS-1300
AC: Approximately 0.1 W
DC: Approximately 0.1 W
ADS-1350W
AC: Approximately 0.1 W
DC: Approximately 0.1 W
ADS-1800W
AC: Approximately 0.1 W
DC: Approximately 0.1 W
Dimensions
1: 85 mm
2: 288 mm
3: 205 mm
4: 211 mm
5: 101 mm
Weights
ADS-1300: Approximately 1.37 kg
ADS-1350W: Approximately 1.37 kg
ADS-1800W: Approximately 1.42 kg
Temperature
Operating
5°C to 35°C
Storage
0°C to 40°C
Humidity
Operating
20% to 80%
Storage
10% to 90%
ADF (Automatic Document Feeder)
Up to 20 sheets
(Paper: 80 g/ A4/Letter size)
*1
USB Type-C is supported.
*2
The AC Adapter is an optional accessory and is available on the Brother website by searching for part number LK-1001C.
*3
Measured diagonally.
*4
Measured when the machine is connected to your computer.
*5
When the USB port is connected.
*6
When using 2-sided (duplex) colour scanning at resolutions 300 x 300 dpi.
Document Specifications
Paper Type
Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Non Carbon Paper, Receipt, Recycled Paper, Business Card, Plastic Card
Document Size
Width
50.8 mm to 215.9 mm
Length *1
70 mm to 355.6 mm
Carrier Sheet Restrictions
Width
Documents narrower than 50.8 mm
Length
Documents shorter than 70 mm
Thickness
Pages thinner than 0.08 mm
*1
Up to 5000 mm when using the Long Paper function.
Scanner Specifications
Colour/Monochrome
Yes/Yes
TWAIN Compliant
Windows
Windows 10 / Windows 11
WIA Compliant
Windows
Windows 10 / Windows 11
ICA Compliant
(ADS-1300)
Mac
macOS v11.x / macOS 12.x / macOS 13.x
Colour Depth
Input
48 bit colour processing
Output
24 bit colour processing
Resolution
Interpolated
Up to 1200 x 1200 dpi
Optical
Up to 600 x 600 dpi
Scanning Width
Up to 215.9 mm
Greyscale
256 levels
Max. Speed
For detailed specifications, visit www.brother.com.
Direct Scan Feature (Scan to USB) Specifications
Compatible Media
USB flash drive *1
Interface
Interface USB 2.0 Hi Speed
*1
USB Mass Storage standard up to 128 GB
Supported formats: FAT12/FAT16/FAT32/exFAT
Interface Specifications
USB
USB 3.2 Gen1
Use a USB Type-A to USB Type-C Cable *1 or a USB Type-C to USB Type-C Cable that supports USB Super Speed or USB 2.0 High speed and is no more than 2.0 metres long.
Wireless LAN
(ADS-1350W/ADS-1800W)
2.4 GHz band
IEEE 802.11b/g/n (Infrastructure Mode)
IEEE 802.11g/n (Wi-Fi Direct) (ADS-1800W)
IEEE 802.11g/n (Wireless Direct) (ADS-1350W)
*1
USB Type-A to USB Type-C Cables do not support USB power.
Network Specifications
Wireless Network Security
WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES)
Setup Support Utility
WPS
Supported Protocols and Security Features
Protocol (IPv4)
ADS-1350W
DHCP, APIPA (Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, SNMPv1/v2c/v3, ICMP, Web Services (Scan), SNTP Client
ADS-1800W
DHCP, APIPA (Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, SMTP Client, FTP/SFTP Client, CIFS Client, SNMPv1/v2c/v3, HTTP/HTTPS server, ICMP, Web Services (Scan), SNTP Client
Protocol (IPv6)
ADS-1350W
RA, DNS Resolver, mDNS, LLMNR responder, ICMPv6, Web Services (Scan), SNTP Client, SNMPv1/v2c/v3
ADS-1800W
RA, DNS Resolver, mDNS, LLMNR responder, SMTP Client, FTP Client, CIFS Client, HTTP/HTTPS server, ICMPv6, Web Services (Scan), SNTP Client, SNMPv1/v2c/v3
Network Security (Wireless)
ADS-1350W
SSL/TLS (HTTPS), SNMP v3, 802.1x (EAP-FAST, PEAP, EAP-TLS, EAP-TTLS)
ADS-1800W
SMTP-AUTH, SSL/TLS (HTTPS, SMTP), SNMP v3, SSH, 802.1x (EAP-FAST, PEAP, EAP-TLS, EAP-TTLS)
Network Security (Email)
(ADS-1800W)
SMTP-AUTH, SSL/TLS (SMTP)
Wi-Fi Certification
ADS-1350W
Wi-Fi CERTIFIED™, WPA3™-Enterprise/Personal, Wi-Fi Protected Setup™ (WPS)
ADS-1800W
Wi-Fi CERTIFIED™, WPA3™-Enterprise/Personal, Wi-Fi Protected Setup™ (WPS) , Wi-Fi Direct®
Computer Requirements Specifications
Computer Platform & Operating System Version
Supported PC Software Functions
PC Interface
Processor Minimum Speed
Hard Disk Space to Install
For Drivers
For Applications
Windows Operating System
Windows 10
Windows 11
Scanning
USB
WLAN (Wi-Fi) *1
32bit (x86) or 64bit (x64) processor
70 MB
Drivers, Installer and Software:
1.4 GB
Mac Operating System
macOS v11.x
macOS v12.x
macOS v13.x
64bit processor
30 MB
Drivers and Software:
600 MB
