ASUS COM NB Expertbook PM3606CKA-MB0069, 16" WUXGA, Ryzen AI 7 350, 16GB, 1TB M.2, INT, NOOS, Szürke

Sales Model Name
PM3606CKA-MB0069

EAN Code


UPC Code


WEEE


BASE UNIT
VSNX0981-BU0510

Operating System
Non-preinstalled OS

LCD cover-material
Aluminum

LCD cover-color
Misty Grey

Top case-material
Aluminum

Top case-color
Misty Grey

Bottom case-material
Aluminum

Bottom case-color
Misty Grey

Military grade
US MIL-STD 810H military-grade standard

Panel Size
16.0-inch

Backlit
LED Backlit

Brightness
300nits

Resolution
WUXGA (1920 x 1200) 16:10

Glare
Anti-glare display

Color gamut
NTSC: 45%

View angle(H/V)
178/178

Response time(Typ/Max) (ms)
25/30

Refresh rate
60Hz

Contrast  (Typ)
1000:1

Touch Panel
Non-touch screen

Screen-to-body ratio
88 %

IPS-level
Wide view

Processor
AMD Ryzen™AI 7 350 Processor 2.0GHz (16MB Cache, up to 5.0 GHz, 8 cores)NPU 50 TOPs

Neural processor
AMD Ryzen™ AI over 40 TOPs

Chipset
N/A

Discrete/Share
Share

Integrated GPU
AMD Radeon™ Graphics

VRAM
N/A

How to upgrade memory
Upgradable Need to remove bottom/top case

Expansion Slot(includes used)
2x DDR5 SO-DIMM slots1x M.2 2230 PCIe 4.0x41x M.2 2280 PCIe 4.0x4

DIMM Memory
16GB DDR5 SO-DIMM

Total System Memory
DDR5 16GB

Storage
1TB M.2 2280 NVMe™ PCIe® 4.0 SSD

Front-facing camera
1080p FHD cameraWith privacy shutter

Wireless
Wi-Fi 7(802.11be) (Triple band) 2*2 + Bluetooth® 5.4 Wireless Card

NumberPad
N/A

FingerPrint
FingerPrint

Keyboard type
Backlit Chiclet Keyboard

I/O ports
2x USB 3.2 Gen 1 Type-A2x USB 3.2 Gen 2 Type-C support display / power delivery1x HDMI 2.1 TMDS1x 3.5mm Combo Audio Jack1x RJ45 Gigabit Ethernet

Audio
Audio by DiracSmart Amp TechnologyBuilt-in speakerBuilt-in array microphone

Battery
70WHrs, 4S1P, 4-cell Li-ion

AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal

Required charging power


Dimension (WxHxD)
35.84 x 25.35 x 1.79 ~ 1.80 cm (14.11" x 9.98" x 0.70" ~ 0.71")

Weight (with Battery)
1.87 kg (4.12 lbs)

Weight (w/o Battery)
1.61 kg (3.55 lbs)

Security
Fingerprint sensor integrated with Power KeyKensington Nano Security Slot™(6x 2.5mm)McAfee® 30 days free trialBIOS Integrity Measurement SupportBIOS Self RecoveryMicrosoft Secured-core PCMicrosoft Security Level 3Support Absolute Persistence 2.0 (Computrace)Trusted Platform Module (TPM) 2.0N/A

MyASUS feature
System diagnosisBattery health chargingFan ProfileSplendidTru2LifeFunction key lockWiFi SmartConnectAppDealsLink to MyASUS

Built-in Apps
MyASUSAI ExpertMeet (AI features need devices with 12GB RAM or more)

Disclaimer for Built-in Apps
Built-in Apps vary from OS SKU.*MyASUS/McAfee don"t support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)

Reparability Index (for France)
8.0

Ecolabels & Compliances
FSC Recycled

Base Warranty
3Y Pick up/ return

Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgradeACX13-007023NX//2Y Extension 5Y OnSite Service(Next Business Day)*upgradeACX15-011800NX//3Y OnSite Service(Next Business Day) 3Y Accidental Damage Protection* 3Y HDD_Retention*upgrade*If you would like to know the details, please contact your sales teams.

Battery warranty
Commercial NB P series Battery warranty follow system warranty.

Sustainable Material_Top cover(A part)
30% PCR recycled plastic(cover or inner frame)30% PIR recycled aluminum

Sustainable Material_Keyboard frame (C part)
30% PCR recycled plastic(cover or inner frame)30% PIR recycled aluminum

Sustainable Material_Bottom cover (D part)
30% PCR recycled plastic(cover or inner frame)30% PIR recycled aluminum

Sustainable Material_Battery


Sustainable Material_Keyboard
50% PCR recycled plastic cap50% PIR recycled aluminum bracket

Sustainable Material_Speaker
45% PCR + 5% OBP PCR recycled plastic enclosure

Sustainable Material_Total PCR recycled plastic
22%
