ASUS COM NB Expertbook P5405CSA-NZ1109, 14" WQXGA, Intel Ultra 7 258V, 32GB, 512GB M.2, INT, NOOS, Szürke

Part No
90NX0861-M01H60

Model Name
P5405CSA-NZ1109

EAN Code
4711636548021

UPC Code
199291548022

WEEE
0.833

BASE UNIT
VSNX0861-BU1100




Operating System
Non-preinstalled OS

LCD cover-material
Aluminum

LCD cover-color
Misty Grey

Top case-material
Aluminum

Top case-color
Misty Grey

Bottom case-material
Aluminum

Bottom case-color
Misty Grey

Military grade
US MIL-STD 810H military-grade standard

Panel Size
14.0-inch

Backlit
LED Backlit

Brightness
400nits

Resolution
WQXGA (2560 x 1600) 16:10

Glare
Anti-glare display

Color gamut
sRGB: 100%

View angle(H/V)
178/178

Response time(Typ/Max) (ms)
25/30

Refresh rate
144Hz

Contrast  (Typ)
1200:1

Touch Panel
Non-touch screen

Screen-to-body ratio
90 %

IPS-level
Wide view

Processor
Intel® Core™ Ultra 7 Processor 258V 32GB 2.2 GHz (12MB Cache, up to 4.8 GHz, 8 cores, 8 Threads); Intel® AI Boost NPU up to 47 TOPS

Neural processor
Intel® AI Boost NPU

Chipset
N/A

Discrete/Share
Share

Integrated GPU
Intel® Arc™ 140V GPU

VRAM
N/A

How to upgrade memory
Not Available

Expansion Slot(includes used)
1x M.2 2230 PCIe 4.0x41x M.2 2280 PCIe 4.0x4

On board memory
32GB LPDDR5X Memory on Package

Total System Memory
LPDDR5X 32GB

Storage
512GB M.2 2280 NVMe™ PCIe® 4.0 SSD

Front-facing camera
1080p FHD camera with IR function to support Windows HelloWith privacy shutter

Wireless
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.4 Wireless Card

NumberPad
N/A

FingerPrint
FingerPrint

Keyboard type
Backlit Chiclet Keyboard

I/O ports
2x USB 3.2 Gen 2 Type-A2x Thunderbolt™ 4, compliant with USB4, support display / power delivery1x HDMI 2.11x 3.5mm Combo Audio Jack

Audio
Dolby AtmosSmart Amp TechnologyBuilt-in array microphone

Battery
63WHrs, 3S1P, 3-cell Li-ion

AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal (Adapter+power cord)

Required charging power
Min: 55WMax: 65W*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher.

Dimension (WxHxD)
31.20 x 22.32 x 1.49 ~ 1.64 cm (12.28" x 8.79" x 0.59" ~ 0.65")

Weight (with Battery)
1.29 kg (2.84 lbs)

Weight (w/o Battery)
1.06 kg (2.34 lbs)

Security
Fingerprint sensor integrated with Power KeyIR webcam with Windows Hello supportKensington Nano Security Slot™(6x 2.5mm)BIOS Booting User Password ProtectionBIOS Integrity Measurement SupportBIOS Self RecoveryCSME BIOS Redundancy AssistanceHDD User Password Protection and SecurityIntel CSME Firmware ResilienceIntel® BIOS GuardIntel® Boot GuardMicrosoft Pluton Security ProcessorMicrosoft Security Level 3Support Absolute Persistence 2.0 (Computrace)Trusted Platform Module (TPM) 2.0N/A

MyASUS feature
System diagnosisBattery health chargingFan ProfileSplendidTru2LifeFunction key lockWiFi SmartConnectAppDealsLink to MyASUS

MyExpert Features
ExpertMeet(All)SafeGuard Backup(Dual SSD, additional purchase before shipment)

Built-in Apps
AI ExpertMeet (AI features need devices with 12GB RAM or more)MyASUS

Disclaimer for Built-in Apps
Built-in Apps vary from OS SKU.*MyASUS/McAfee don"t support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)

Reparability Index (for Belgium)
95.2

Reparability Index (for France)
98.3

Ecolabels & Compliances
EPEAT Gold with Climate+Energy star 8.0FSC RecycledREACHRoHSTCO Certified

Base Warranty
3Y Pick up/ return

Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgradeACX13-007023NX//2Y Extension; 5Y OnSite Service(Next Business Day)*upgradeACX14-017300NX//3Y HDD Retention*upgradeACX15-011800NX//3Y OnSite Service(Next Business Day); 3Y Accidental Damage Protection*; 3Y HDD_Retention*upgrade*If you would like to know the details, please contact your sales teams.

Battery warranty
Commercial NB P series Battery warranty follow system warranty.

Sustainable Material_Top cover(A part)
30% PCR recycled plastic(cover or inner frame)30% PIR recycled aluminum

Sustainable Material_Keyboard frame (C part)
30% PCR recycled plastic(cover or inner frame)30% PIR recycled aluminum

Sustainable Material_Bottom cover (D part)
30% PCR recycled plastic(cover or inner frame)30% PIR recycled aluminum

Sustainable Material_Battery
30% PCR recycled plastic

Sustainable Material_Keyboard
50% PCR recycled plastic cap50% PIR recycled aluminum bracket

Sustainable Material_Speaker
45% PCR + 5% OBP PCR recycled plastic enclosure

Sustainable Material_Total PCR recycled plastic
29%
