ASUS COM NB Expertbook P3406CCAP-LY0427 14" WUXGA, Intel Ultra 7 255H, 16GB, 512GB M.2, INT, NOOS, Szürke, Backlit

Part No
90NX0AM1-M00FT0

Model Name
P3406CCAP-LY0427

EAN Code
4711636640268

UPC Code
199291640269

WEEE
1.04

BASE UNIT
VSNX0AM1-BU1121




Operating System
Non-preinstalled OS

LCD cover-material
Plastic

LCD cover-color
Misty Grey

Top case-material
Plastic

Top case-color
Misty Grey

Bottom case-material
Plastic

Bottom case-color
Misty Grey

Military grade
US MIL STD 810H military grade standard (24 procedures)

Panel Size
14.0-inch

Backlit
LED Backlit

Brightness
300nits

Resolution
WUXGA (1920 x 1200) 16:10

Glare
Anti-glare display

Color gamut
NTSC: 45%

View angle(H/V)
160/160

Response time(Typ/Max) (ms)
20/25

Refresh rate
60Hz

Contrast  (Typ)
800:1

Touch Panel
Non-touch screen

Screen-to-body ratio
88 %

IPS-level
Wide view

Processor
Intel® Core™ Ultra 7 Processor 255H 2.0 GHz (24MB Cache, up to 5.1 GHz, 16 cores, 16 Threads); Intel® AI Boost NPU up to 13 TOPS

Neural processor
Intel® AI Boost NPU

Chipset
N/A

Discrete/Share
Share

Integrated GPU
Intel® Graphics

VRAM
N/A

How to upgrade memory
Upgradable; Need to remove bottom/top case

Expansion Slot(includes used)
2x DDR5 SO-DIMM slots1x M.2 2230 PCIe 4.0x41x M.2 2280 PCIe 4.0x4

DIMM Memory
16GB DDR5 SO-DIMM

Total System Memory
DDR5 16GB

Storage
512GB M.2 2280 NVMe™ PCIe® 4.0 SSD

Front-facing camera
1080p FHD camera with IR function to support Windows HelloWith privacy shutter

Wireless
Wi-Fi 6(802.11ax) (Dual band) 2*2 + Bluetooth® 5.4 Wireless Card

NumberPad
N/A

FingerPrint
FingerPrint

Keyboard type
Backlit Chiclet Keyboard

Keyboard language
Hungarian

I/O ports
1x USB 3.2 Gen 2 Type-C support display / power delivery2x USB 3.2 Gen 1 Type-A1x Thunderbolt™ 4, compliant with USB4, support display / power delivery1x HDMI 2.1 TMDS1x 3.5mm Combo Audio Jack1x RJ45 Gigabit Ethernet

Audio
Audio by DiracBuilt-in speakerBuilt-in array microphone

Battery
70WHrs, 4S1P, 4-cell Li-ion

AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal (Adapter+power cord)

Required charging power
Min: 55WMax: 65W*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher.

Dimension (WxHxD)
31.60 x 22.78 x 1.17 ~ 1.99 cm (12.44" x 8.97" x 0.46" ~ 0.78")

Starting Weight (with Battery)
1.56 kg (3.44 lbs)

Starting Weight (w/o Battery)
1.30 kg (2.87 lbs)

Security
Kensington Nano Security Slot™(6x 2.5mm)Fingerprint sensor integrated with Power KeyIR webcam with Windows Hello supportEnhanced Password StrengthHDD User Password Protection and SecurityIntel® Boot GuardTrusted Platform Module (Firmware TPM)BIOS setup user passwordCSME BIOS Redundancy AssistanceBIOS Booting User Password ProtectionBIOS Integrity Measurement SupportBIOS Self RecoverySupport Absolute Persistence 2.0 (Computrace)Intel CSME Firmware ResilienceMicrosoft Security Level 3Intel® BIOS GuardASUS ExpertGurdian with NIST SP 800 155 complianceN/A

MyASUS feature
System diagnosisBattery health chargingFan ProfileSplendidTru2LifeFunction key lockWiFi SmartConnectAppDeals

MyExpert Features
Advanced ToolExpertMeet(All)SafeGuard Backup(Dual SSD, additional purchase before shipment)

Built-in Apps
MyASUSASUS MyExpert (Not supported in China, 16GB RAM or higher)AI ExpertMeet (China only)

Disclaimer for Built-in Apps
Built-in Apps vary from OS SKU.*MyASUS/McAfee don"t support in Clean Build/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)

Reparability Index (for Belgium)
09.2

Reparability Index (for France)
09.7

Ecolabels & Compliances
Energy star 9.0FSC RecycledREACHRoHS

Base Warranty
3Y Pick up/ return

Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgradeACX13-007023NX//2Y Extension; 5Y OnSite Service(Next Business Day)*upgradeACX15-005821NX//2Y Extension; 5Y OnSite Service(Next Business Day); 5Y HDD Retention*upgrade*If you would like to know the details, please contact your sales teams.

Battery warranty
Commercial NB P series Battery warranty follow system warranty.

Sustainable Material_Top cover(A part)
30% PCR recycled plastic(cover or inner frame)30% PIR recycled aluminum

Sustainable Material_Keyboard frame (C part)
30% PCR recycled plastic(cover or inner frame)

Sustainable Material_Bottom cover (D part)
30% PCR recycled plastic(cover or inner frame)

Sustainable Material_Battery
30% PCR recycled plastic

Sustainable Material_Keyboard
50% PCR recycled plastic cap

Sustainable Material_Speaker
45% PCR + 5% OBP PCR recycled plastic enclosure

Sustainable Material_Total PCR recycled plastic
28.2%
