ASUS COM NB ExpertBook B5605CCA-MB0229X 16" WUXGA, Ultra 7-255H, 16GB, 512GB M.2, INT, WIN11PRO, Szürke

Sales Model Name
B5605CCA-MB0229X

EAN Code
4711636308342

UPC Code
199291308343

WEEE
1.358

BASE UNIT
VSNX08F1-BUA104

Operating System
Windows 11 Pro

Office
1-month trial for new Microsoft 365 customers. Credit card required.

LCD cover-material
Aluminum

LCD cover-color
Gentle Grey

Top case-material
Aluminum

Top case-color
Gentle Grey

Bottom case-material
Aluminum

Bottom case-color
Gentle Grey

Military grade
US MIL-STD 810H military-grade standard

Panel Size
16.0-inch

Backlit
LED Backlit

Brightness
300nits

Resolution
WUXGA (1920 x 1200) 16:10

Glare
Anti-glare display

Color gamut
NTSC: 45%

View angle(H/V)
178/178

Response time(Typ/Max) (ms)
25/30

Refresh rate
60Hz

Contrast  (Typ)
1000:1

Touch Panel
Non-touch screen

Screen-to-body ratio
85 %

IPS-level
Wide view

Processor
Intel® Core™ Ultra 7 Processor 255H 2.0 GHz (24MB Cache, up to 5.1 GHz, 16 cores, 16 Threads) Intel® AI Boost NPU up to 13 TOPS

Neural processor
Intel® AI Boost NPU

Chipset
N/A

Discrete/Share
Share

Integrated GPU
Intel® Arc™ Graphics(available for Intel® Core™ Ultra H 5/7/9 with dual channel memory)

VRAM
N/A

How to upgrade memory


Expansion Slot(includes used)
2x DDR5 SO-DIMM slots

DIMM Memory
16GB DDR5 SO-DIMM

Total System Memory
DDR5 16GB

Storage
512GB M.2 2280 NVMe™ PCIe® 4.0 SSDSSD Housing for storage expansion

Front-facing camera
1080p FHD cameraWith privacy shutter

Wireless
Wi-Fi 7(802.11be) (Triple band) 2*2 + Bluetooth® 5.4 Wireless Card

NumberPad
N/A

FingerPrint
FingerPrint

Keyboard type
Backlit Chiclet Keyboard

I/O ports
2x USB 3.2 Gen 1 Type-A2x Thunderbolt™ 4, compliant with USB4, supports display / power delivery1x HDMI 2.1 TMDS1x 3.5mm Combo Audio Jack1x RJ45 Gigabit EthernetMicro SD card reader

Audio
Audio by Dirac

Battery
50WHrs, 3S1P, 3-cell Li-ion

AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal

Required charging power
Min: 55WMax: 65W*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher.

Dimension (WxHxD)
35.84 x 25.39 x 1.75 ~ 1.79 cm (14.11" x 10.00" x 0.69" ~ 0.70")

Weight (with Battery)
1.74 kg (3.84 lbs)

Weight (w/o Battery)
1.55 kg (3.42 lbs)

Security
Fingerprint sensor integrated with Power KeyKensington Nano Security Slot™(6x 2.5mm)BIOS Booting User Password ProtectionBIOS Integrity Measurement SupportBIOS Self RecoveryBIOS setup user passwordCSME BIOS Redundancy AssistanceEnhanced Password StrengthHDD User Password Protection and SecurityIntel CSME Firmware ResilienceIntel® BIOS GuardIntel® Boot GuardMicrosoft Security Level 2Support Absolute Persistence 2.0 (Computrace)Trusted Platform Module (TPM) 2.0N/A
