ASUS COM NB ExpertBook B3604CMA-Q91223 16" WUXGA, Intel Ultra 5 125H, 8GB, 512GB M.2, INT, NOOS, Fekete

Part No
90NX0731-M01J20


Sales Model Name
B3604CMA-Q91223


EAN Code
4711387953235


UPC Code
197105953239


WEEE
1.547


BASE UNIT
VSNX0731-BUA114


Operating System
Non-preinstalled OS


Office



LCD cover-material
Aluminum


LCD cover-color
Star Black


Top case-material
Plastic


Top case-color
Star Black


Bottom case-material
Plastic


Bottom case-color
Black


Military grade
US MIL-STD 810H military-grade standard


Panel Size
16.0-inch


Backlit
LED Backlit


Brightness
300nits


Resolution
WUXGA (1920 x 1200) 16:10


Glare
Anti-glare display


Color gamut
NTSC: 45%


View angle(H/V)
178/178


Response time(Typ/Max) (ms)
11/9


Refresh rate
60Hz


Contrast  (Typ)
1000:1


Touch Panel
Non-touch screen


Screen-to-body ratio
85 %


IPS-level
Wide view


Processor
Intel® Core™ Ultra 5 Processor 125H 1.2 GHz (18MB Cache, up to 4.5 GHz, 14 Cores) Intel® AI Boost NPU


Neural processor
Intel® AI Boost NPU


Chipset
N/A


Discrete/Share
Share


Integrated GPU
Intel® Graphics


VRAM
N/A


How to upgrade memory
Upgradable Need to remove bottom/top case


Expansion Slot(includes used)
2x DDR5 SO-DIMM slots1x M.2 2230 PCIe 4.0x41x M.2 2280 PCIe 4.0x4


DIMM Memory
8GB DDR5 SO-DIMM


Total System Memory
DDR5 8GB


Storage
512GB M.2 2280 NVMe™ PCIe® 4.0 SSDSSD Housing for storage expansion


Front-facing camera
720p HD cameraWith privacy shutter


Wireless
Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth® 5.3 Wireless Card


NumberPad
N/A


FingerPrint
FingerPrint


Keyboard type
Backlit Chiclet Keyboard


I/O ports
2x USB 3.2 Gen 2 Type-A2x Thunderbolt™ 4, compliant with USB4, supports display / power delivery1x HDMI 2.1 TMDS1x 3.5mm Combo Audio Jack1x RJ45 Gigabit Ethernet


Audio
Audio by DiracBuilt-in speakerBuilt-in array microphone


Battery
50WHrs, 3S1P, 3-cell Li-ion


AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal


Dimension (WxHxD)
35.80 x 25.43 x 2.03 ~ 2.03 cm (14.09" x 10.01" x 0.80" ~ 0.80")


Weight (with Battery)
1.90 kg (4.19 lbs)


Weight (w/o Battery)
1.71 kg (3.77 lbs)


Security
Fingerprint sensor integrated with Power KeyKensington Nano Security Slot™(6x 2.5mm)BIOS Booting User Password ProtectionBIOS setup user passwordHDD User Password Protection and SecuritySupport Absolute Persistence 2.0 (Computrace)Trusted Platform Module (TPM) 2.0N/A


Antivirus



MyASUS feature
System diagnosisBattery health chargingFan ProfileSplendidTru2LifeFunction key lockWiFi SmartConnectAppDealsLink to MyASUS


Built-in Apps
MyASUS


Disclaimer for Built-in Apps
Built-in Apps vary from OS SKU.*MyASUS/McAfee don"t support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)


Reparability Index (for France)
9.5


Ecolabels & Compliances
EPEAT GoldEnergy star 8.0FSC MixREACHRoHSTCO Certified


Base Warranty
3Y Pick up/ return


Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgradeACX13-007023NX//2Y Extension 5Y OnSite Service(Next Business Day)*upgradeACX14-017300NX//3Y HDD Retention*upgrade*If you would like to know the details, please contact your sales teams.


Battery warranty
Commercial NB B series Battery warranty follow system warranty, 4Y-5Y by WEP option.


Sustainable Material_Top cover(A part)
50% PIR recycled aluminum


Sustainable Material_Keyboard frame (C part)
30% PCR recycled plastic(cover or inner frame)


Sustainable Material_Bottom cover (D part)
35% PCR recycled plastic(cover or inner frame)


Sustainable Material_Battery



Sustainable Material_Keyboard
50% PCR recycled plastic cap


Sustainable Material_Speaker
45% PCR + 5% OBP PCR recycled plastic enclosure


Sustainable Material_Total PCR recycled plastic
30.8%
