ASUS COM NB ExpertBook B3405CCA-LY0246 14" WUXGA, Ultra 5 125H, 8GB, 512GB M.2, INT, NOOS, Szürke

Sales Model Name
B3405CCA-LY0246

EAN Code


UPC Code


WEEE
1.3

BASE UNIT
VSNX08L1-BU3111

Operating System
Non-preinstalled OS

Office


LCD cover-material
Aluminum

LCD cover-color
Gentle Grey

Top case-material
Plastic

Top case-color
Gentle Grey

Bottom case-material
Plastic

Bottom case-color
Gentle Grey

Military grade
US MIL-STD 810H military-grade standard

Panel Size
14.0-inch

Backlit
LED Backlit

OLED


Brightness
300nits

Resolution
WUXGA (1920 x 1200) 16:10

Glare
Anti-glare display

Color gamut
NTSC: 45%

View angle(H/V)
170/170

Response time(Typ/Max) (ms)
20/25

Refresh rate
60Hz

Contrast  (Typ)
800:1

Touch Panel
Non-touch screen

Screen-to-body ratio
84 %

Pantone


IPS-level
Wide view

VESA CERTIFIED Display HDR


Processor
Intel® Core™ Ultra 5 Processor 125H 1.2 GHz (18MB Cache, up to 4.5 GHz, 14 Cores, 18 Threads) Intel® AI Boost NPU

Neural processor
Intel® AI Boost NPU

Chipset
N/A

Discrete/Share
Share

Integrated GPU
Intel® Graphics

VRAM
N/A

How to upgrade memory
Upgradable Need to remove bottom/top case

Expansion Slot(includes used)
2x DDR5 SO-DIMM slots1x M.2 2230 PCIe 4.0x41x M.2 2280 PCIe 4.0x4While selecting the LTE/5G specification, the 2230 SSD can’t be installed additionally due to design limitation.

On board memory


DIMM Memory
8GB DDR5 SO-DIMM

Total System Memory
DDR5 8GB

Storage
512GB M.2 2280 NVMe™ PCIe® 4.0 SSDSSD Housing for storage expansion

Front-facing camera
1080p FHD cameraWith privacy shutter

Wireless
Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth® 5.4 Wireless Card

On board Wireless


NumberPad
N/A

FingerPrint
FingerPrint

Keyboard type
Backlit Chiclet Keyboard

I/O ports
2x USB 3.2 Gen 1 Type-A2x USB 3.2 Gen 2 Type-C support display / power delivery1x HDMI 2.1 TMDS1x 3.5mm Combo Audio Jack1x RJ45 Gigabit EthernetMicro SD card reader

Audio
Audio by DiracSmart Amp TechnologyBuilt-in speakerBuilt-in array microphone

Battery
50WHrs, 3S1P, 3-cell Li-ion

AC Adapter
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal

Required charging power
Min: 55WMax: 65W*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher.

Dimension (WxHxD)
31.51 x 22.68 x 1.89 ~ 1.90 cm (12.41" x 8.93" x 0.74" ~ 0.75")

Weight (with Battery)
1.49 kg (3.28 lbs)

Weight (w/o Battery)
1.30 kg (2.87 lbs)

Security
Fingerprint sensor integrated with Power KeyKensington Nano Security Slot™(6x 2.5mm)BIOS Booting User Password ProtectionBIOS Integrity Measurement SupportBIOS Self RecoveryBIOS setup user passwordCSME BIOS Redundancy AssistanceEnhanced Password StrengthHDD User Password Protection and SecurityIntel CSME Firmware ResilienceIntel® BIOS GuardIntel® Boot GuardMicrosoft Secured-core PCMicrosoft Security Level 2Support Absolute Persistence 2.0 (Computrace)Trusted Platform Module (TPM) 2.0N/A

Antivirus


MyASUS feature
System diagnosisBattery health chargingFan ProfileSplendidTru2LifeFunction key lockWiFi SmartConnectAppDealsLink to MyASUS

Built-in Apps
MyASUSAI ExpertMeet (AI features need devices with 12GB RAM or more)

Disclaimer for Built-in Apps
Built-in Apps vary from OS SKU.*MyASUS/McAfee don"t support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu)

Included in the Box


Reparability Index (for France)
9.9

Reparability Index (for Belgium)
9.5

Ecolabels & Compliances
EPEAT Gold with Climate+Energy star 8.0FSC RecycledREACHRoHSTCO Certified

Base Warranty
3Y Pick up/ return

Recommended Warranty Package Part number//Extension and/or upgrade service from base warranty
ACX13-007003NX//3Y OnSite Service(Next Business Day)*upgradeACX13-007023NX//2Y Extension 5Y OnSite Service(Next Business Day)*upgradeACX14-017300NX//3Y HDD Retention*upgradeACX15-011800NX//3Y OnSite Service(Next Business Day) 3Y Accidental Damage Protection* 3Y HDD_Retention*upgrade*If you would like to know the details, please contact your sales teams.

Battery warranty
Commercial NB B series Battery warranty follow system warranty, 4Y-5Y by WEP option.

Sustainable Material_Top cover(A part)
30% PCR recycled plastic(cover or inner frame)30% PIR recycled aluminum

Sustainable Material_Keyboard frame (C part)
30% PCR recycled plastic(cover or inner frame)

Sustainable Material_Bottom cover (D part)
30% PCR recycled plastic(cover or inner frame)

Sustainable Material_Battery
30% PCR recycled plastic

Sustainable Material_Keyboard
50% PCR recycled plastic cap

Sustainable Material_Speaker
45% PCR + 5% OBP PCR recycled plastic enclosure

Sustainable Material_Total PCR recycled plastic
29%
