CAMERA
Image Sensor
1/2.7 Progressive Scan CMOS
Day/Night Switch
Unified/ Scheduled/ Auto
Shutter Speed
1/3 to 1/10000 s
Slow Shutter
Yes
Minimum Illumination
0.005 Lux; 0 Lux with IR/white light
Day/Night Mechanism
IR Cut Filter
NETWORK
Protocol
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
ONVIF
Yes
API
Open Network Video Interface (Profile S)
Simultaneous Live View
3 Main Streams & 3 Sub-Streams
Client
VIGI App, VIGI Security Manager
Web Browser
Google ChromeŽ 57 and aboveFirefoxŽ 52 and aboveSafariŽ 11 and aboveMicrosoftŽ Edge 91 and above
Cloud
Yes
Security
Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
GENERAL
Operating Temperature
-3060 °C
Storage Temperature
-4060 °C
Operating Humidity
95% or Less (Non-Condensing)
Storage Humidity
95% or Less (Non-Condensing)
Package Contents
VIGI Network CameraQuick Start GuideWaterproof Cable AttachmentsMounting Accessories
Material
Plastic
Power Supply
12V DC ą 5%, Max. 9 W, 5.5 mm Coaxial Power PlugPoE: 802.3af/at, class 0, Max. 10.5 W
Protection
IP67
Product Dimensions (L x W x H)
78.42× 186.88× 71.55 mm
Certifications
CE, NTRA, VCCI, KC, BSMI, FCC, IC
INTERFACES
Network Interface
1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE
Alarm
N/A
Reset Button
Yes
Power
DC Power Port
On-board Storage
Built-In Memory Card Slot, Support MicroSD Card, up to 256 GB
Built-in Microphone
Yes; Records Anything Going on within a 15-ft Radius of the Camera
Built-in Speaker
Yes
Audio
N/A
ALARM AND EVENT MANAGEMENT
Smart Event
Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned Detection, Object Removal Detection, Loitering Detection, Scene Change Detection
Basic Event
Motion Detection, Video Tampering Detection, Exception ( Illegal Login), Scene Change Detection
Alarm Linkage
Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing
Linkage Method
N/A
Output Notification
Message Push
DEEP LEARNING FUNCTION
People & Vehicle Analytics
Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.
Multi-Target-Type Detection
Supports Simultaneous Detection and Capture of Human Body and Vehicle
Face Capture
N/A
Face Comparison
N/A
LENS
Type
Fixed Focal Lens
Focal Length
4 mm
Aperture
F1.6
FOV
2.8mm:Horizontal FOV: 109°, Vertical FOV: 57°, Diagonal FOV: 128°4mm:Horizontal FOV: 90°, Vertical FOV: 48°, Diagonal FOV: 107°6mm:Horizontal FOV: 56°, Vertical FOV: 30.5°, Diagonal FOV: 66°
Lens Mount
M12*P 0.5
DORI Distance
2.8 mmDetect: 63 m (206 ft)Observe: 85 m (109 ft)Recognize: 12 m (39 ft)Identify: 6 m (19 ft)4 mmDetect: 80 m (262 ft)Observe: 33 m (109 ft)Recognize: 16 m (52 ft)Identify: 8 m (26 ft)6 mmDetect: 120 m (393 ft)Observe: 50 m (164 ft)Recognize: 24 m (78 ft)Identify: 12 m (39 ft)
ANGLE ADJUSTMENT (MANUAL)
Range
Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
AUDIO
Audio Communication
Two-Way Audio
Audio Input
Yes
Audio Output
Yes
Audio Compression
Yes
Audio Sampling Rate
8KHz
Environment Noise Filtering
Yes
Audio Bit Rate
64 Kbps(G.711 alaw)
ILLUMINATOR
IR LED
Quantity: 2Range: 30mWavelength: 850nm
White LED
Quantity: 2Range: 30m
Illuminator On/Off Control
Auto/Scheduled/Always on/Always off
VIDEO
Max. Resolution
2880 X 1620
Main Stream
Frame Rate:50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution:2880x1620,2688x1520, 2304x1296, 2048x1280, 1920x1080,1280x720Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Sub-Stream
Frame Rate:50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fpsResolution:704x576,640x480, 352x288, 320x240Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps.
Bit Rate Control
CBR, VBR
Video Compression
Main Stream: H.265+/H.265/H.264+/H.264Sub-Stream: H.265/H.264
H.264 Type
Main Profile/High Profile
H.264+
Main Stream Supported
H.265 Type
Main Profile
H.265+
Main Stream Supported
Video Bit Rate
Main Stream: 256 Kbps to 6 MbpsSub-Stream: 64 Kbps to 512 Kbps
Image Settings
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software
Image Enhancement
BLC/3D DNR/HLC/SmartIR
Wide Dynamic Range
120 dBNote: When People & Vehicle Analytics is enabled, only DWDR is supported.
SNR
52 dB
Image Parameters Switch
Yes
Privacy Mask
Up to 4 Masks
ROI
1 Region
OSD Setting
Yes
